Shelly Wall Display 4″ — wall-mounted touchscreen to control your entire home
Shelly Wall Display 4″ — wall-mounted touchscreen to control the whole house
It replaces your light switch and brings your entire smart home to a 4-inch touchscreen.
The Shelly Wall Display takes the place of a standard wall switch in a flush-mounting box and connects to 230 V. Behind its 4-inch color touchscreen, it controls Shelly devices around the house, directly operates a circuit thanks to its integrated relay, and continuously measures the room's temperature, humidity, and brightness. Shelly claims an installation time of about ten minutes, replacing the existing switch.
Key features
- 4-inch color touchscreen, customizable home screen
- Integrated relay: 230 V~, 5 A — controls a circuit independently
- Built-in ambient temperature, humidity, and brightness sensors
- Monitor energy consumption of devices in a room via the Shelly Smart Control account
- Wi-Fi 802.11 b/g/n and Bluetooth 4.2 — no gateway required
- Home Assistant and MQTT integration
- Glass, aluminum, and plastic housing, 85 × 85 × 30 mm, available in black or white
- Fits in place of a standard light switch, in a standard flush-mounting box
Main characteristics
- A switch that becomes a dashboard — Replacing an ordinary light switch, the Wall Display shows your Shelly devices, scenes, and room status. The home screen is modular: you choose what is displayed—lights, shutters, temperature, scenes—and in what order.
- Independent control — It includes a built-in relay output for up to 230 V~ and 5 A. The display doesn't just control other devices; it keeps local control over the circuit of the switch it replaces, with an added input for a wired button or switch.
- Three room sensors — Ambient temperature, humidity, and brightness are measured by the device itself. This allows for automation based on the room's actual temperature rather than a theoretical setpoint. Shelly notes that the device does not have an internal temperature probe.
- Installation requirements — The unit measures 85 × 85 × 30 mm and weighs 180 g. It installs in a flush-mounting box with neutral and live 230 V connections on its screw terminals (0.5 to 2.5 mm²). A neutral wire is required: not all switch boxes have one, so check this before ordering.
- Home Assistant and MQTT — The device integrates with Home Assistant and supports MQTT, with 20 schedules and 20 webhooks. Shelly does not list Alexa, Google Home, or SmartThings compatibility for this model, so we choose not to advertise it.
Technical specifications
| Feature | Detail |
|---|---|
| Display | 4-inch color touchscreen |
| Integrated relay | 1 relay output — 230 V~, 5 A maximum |
| Manufacturer Part Number | SAWD1 |
| Power supply | 230 V~, 50/60 Hz |
| Power consumption | < 1 W |
| Inputs | 1 switch/button input on terminal block, 2 power inputs on terminal block (N and L) |
| Ambient temp. sensor | Yes |
| Humidity sensor | Yes |
| Brightness sensor | Yes |
| Wi-Fi | 802.11 b/g/n, 2401–2495 MHz, < 20 dBm — up to 30 m indoors, 50 m outdoors |
| Bluetooth | 4.2, 2400–2483.5 MHz, < 4 dBm — up to 10 m indoors, 30 m outdoors |
| Processor | MTK6580 |
| Memory | 1 GB RAM, 8 GB storage |
| Dimensions (H × W × D) | 85 × 85 × 30 mm |
| Weight | 180 g |
| Housing materials | Plastic, aluminum, and glass |
| Housing colors | Black or white |
| Mounting | Flush-mounting box |
| Screw terminals | Conductors 0.5 to 2.5 mm², stripping 6 to 7 mm, torque 0.4 Nm |
| Operating temperature | −20 °C to 40 °C |
| Humidity | 30% to 70% RH |
| Maximum altitude | 2,000 m |
| Supported loads | Resistive (incandescent lamps, heating appliances), capacitive (capacitor banks, electronic equipment) |
| Automation | 20 schedules, 20 webhooks (2 URLs per webhook), MQTT |
| Integration | Home Assistant |
Fast delivery & secure payment
Shipping across Morocco, with payment upon delivery. Our team is available via WhatsApp to help you with setup and accessory selection.
Included in your purchase
- 1 × Shelly Wall Display 4″ (ref. SAWD1)
- Manufacturer documentation provided with the device
- Installation by an electrician: at your own expense; we can guide you
Brico MIM After-Sales Service
The product arrives new, in its original Shelly packaging. No warranty duration is provided for this reference: we prefer not to promise anything rather than put forward an unverifiable figure.
Customer service via phone, WhatsApp, and email, Monday to Saturday.
Frequently Asked Questions
Is a neutral wire required in the box?
Yes. The device connects to the neutral and phase at 230 V. Many old switch boxes only provide the phase: this is the first thing to have checked by your electrician.
Does it fit into a standard wall box?
The housing measures 85 × 85 × 30 mm and mounts in a wall box. The depth available behind the equipment is the point to check; if in doubt, send us a photo of the open box via WhatsApp.
Can it control a device directly?
Yes, via its built-in relay, up to 230 V~ and 5 A. Shelly indicates that it accepts resistive and capacitive loads.
Does it work with Alexa or Google Home?
Shelly does not publish Alexa, Google Home, or SmartThings capabilities for this model. What the manufacturer documents is Home Assistant and MQTT integration. We only promise what is documented.
Does it measure electricity consumption?
It displays the consumption of the Shelly devices in the room from your Shelly Smart Control account. It is a report from Shelly metering devices, not a measurement made by the screen itself.
Black or white?
Shelly produces both shades. Tell us which one you want when ordering and we will confirm availability.
What is the delivery time?
24 to 48 hours on the Casablanca–Rabat axis, 48 to 72 hours for other cities in Morocco.
