4-channel 5 MP WizSense XVR recorder ref. XVR5104HS-I3 — Dahua
🛠 Installation service available
After your order, our team will call you to confirm compatibility, pricing, and the appointment anywhere in Morocco.
4-Channel 5 MP WizSense XVR Recorder ref. XVR5104HS-I3 — Dahua
4-Channel 5 MP Penta-brid XVR with WizSense AI, the essential choice for home or business.
The Dahua XVR5104HS-I3 is a compact recorder for up to 4 HD analog cameras (up to 5 MP), expandable to 6 channels with IP cameras. It automatically recognizes HDCVI, AHD, TVI, and CVBS cameras, filters alerts using WizSense AI, and saves disk space with Smart H.265+ compression.
Key Features
- 4 HD analog channels up to 5 MP
- Up to 6 IP channels (6 MP IP cameras)
- WizSense AI: SMD Plus, perimeter protection
- HDMI + VGA outputs (1080p)
- Smart H.265+ compression
- 1 SATA disk up to 16 TB (not included)
Main Specifications
- The ideal base kit — With 4 Dahua 5 MP cameras and a hard drive, you can equip your home or small business with a complete and reliable system.
- Filtered alerts — SMD Plus distinguishes between humans and vehicles: your phone won't buzz for a stray cat or moving tree.
- Economical — Smart H.265+ and AI Coding reduce video file sizes. Power consumption under 5 W (without HDD).
- Audio and monitoring — Audio over coaxial cable for cameras with microphones, two-way audio, and remote monitoring via the DMSS app.
Technical Data Sheet
| Feature | Detail |
|---|---|
| Model | DH-XVR5104HS-I3 |
| Analog channels | 4 BNC, auto-detection HDCVI / AHD / TVI / CVBS |
| IP channels | Up to 6 (2 native IP + 4 converted), IP camera up to 6 MP |
| Supported inputs (CVI) | 5MP, 4MP, 1080p, 720p |
| Recording | 5M-N up to 25 fps (channels 1–2), 12 fps other channels; 4M-N/1080p up to 30 fps (channels 1–2) |
| Compression | AI Coding, Smart H.265+, H.265, Smart H.264+, H.264 |
| AI functions (WizSense) | SMD Plus 4 channels; perimeter protection 4 channels (general mode); face recognition 1 channel; QuickPick 2.0 |
| Video outputs | 1 HDMI + 1 VGA (up to 1920×1080) |
| Multi-screen display | 1/4 (1/4/6 with IP expansion) |
| Audio | Input 1 RCA + 4 coaxial audio; output 1 RCA; two-way audio |
| Network | 1 RJ-45 10/100 Mbps |
| Storage | 1 SATA, up to 16 TB (disk not included) |
| USB | 2 USB 2.0 (1 front, 1 rear) |
| Power supply | 12 V DC, 1.5 A |
| Consumption | < 5 W (without disk) |
| Operating temperature | -10 °C to +55 °C |
| Dimensions | 260.0 × 237.8 × 47.6 mm |
| Net weight | 0.84 kg |
Fast delivery & secure payment
Shipping throughout Morocco, with payment on delivery. Our team is available via WhatsApp to help you with setup and selecting accessories.
Included in your purchase
- 1 × Dahua XVR5104HS-I3 recorder (ref. XVR-DAH-5MP-4-CHA)
- Hard drive not included (see our hard drives)
Brico MIM after-sales service
The product arrives new, in its original packaging. No specific warranty duration is provided for this reference: we prefer not to make any claims rather than provide an unverifiable figure.
Customer service available by phone, WhatsApp, and email, Monday to Saturday.
Frequently asked questions
Is the hard drive included?
No. Add a SATA disk from our Video Surveillance Accessories department (1 TB is enough for several days with 4 cameras, depending on settings).
Does it accept 4K cameras?
No, it supports up to 5 MP in analog. For 4K cameras, choose the XVR5104HS-4KL-I3.
Can I view my cameras on my phone?
Yes, with the free Dahua DMSS app.
What is the delivery time?
24 to 48 hours for the Casablanca–Rabat area, 48 to 72 hours for other Moroccan cities.
Order now on Brico MIM
Dahua 4-channel 5 MP XVR5104HS-I3 recorder at 550.00 MAD — fast delivery throughout Morocco, payment on delivery, and Brico MIM after-sales service.
